Description
Box semi trailer has the function of availability and high protection of cargo. These trailers are fully closed and sealed. Therefore, freight is protected from any external influence.
So this box trailer is one of the most commonly seen on the roads.
Enclosed van trailers are used for moving non-perishable food and beverages, household goods, clothing items, plastic, and building products.
Specification of box semi trailer:
| Dimension | 13000mm * 2500mm * 4000mm |
| Load Capacity(T) | 60T |
| Axle | 3 axles |
| Tire | 12 units |
| Suspension | Mechanical suspension |
| King pin | JOST brand 2.0 or 3.5 inch(bolted or welded type) |
| Support leg | JOST brand |
| Main beam | Height: 500mm Upper Plate: 14mm Middle Plate: 8mm
Bottom Plate is 16mm; Material: Q345B Steel |
| Side beam | 16mm or 18mm steel channel ( Material: Q235steel ) |
| Brake chamber | WABCO |
| ABS | Optional |
| Valve | WABCO valve |
| Light | LED light ( specially intended for oversea market ) |
| Voltage | 24V |
| Receptacle | 7-pin Socket ( for 7 wire harness ) |
| Semi Trailer
Surface Coating |
Sandblasted, anti-rust chassis surface is available with 1layer of anticorrosive primer and 2 layers of top coats |
